UT58D General Digital Multimeter | UNI-T
661,25 EGP
UT58D General Digital Multimeter
- 2000 display count, refresh rate 2~3 times/s
- Function symbols and test lead connection indication
- Transistor measurement
- Inductance measurement
- Diode and continuity buzzer, auto power off, overload protection
- Data hold; 20A AC/DC current measurement
Out of stock
Description
UT58D General Digital Multimeter | UNI-T
UT58 series is a safe and reliable manual range digital multimeter that is easy to operate.
Its large 60mm x 54mm LCD screen conveniently displays measurement results.
This series digital multimeter satisfies a variety of applications in both electronics and electrical fields.
Features:
- 2000 display count, refresh rate 2~3 times/s
- Function symbols and test lead connection indication
- Transistor measurement
- Inductance measurement
- Diode and continuity buzzer, auto power off, overload protection
- Data hold; 20A AC/DC current measurement
| Specifications | Range | UT58D |
| DC voltage (V) | 200mV/20V/200V/1000V | ?(0.5%+1) |
| AC voltage (V) | 2V/200V/1000V | ?(0.8%+3) |
| DC current (A) | 2mA/200mA/20A | ?(0.8%+1) |
| AC current (A) | 2mA/200mA/20A | ?(1%+3) |
| Resistance (?) | 200?/2k?/200k?/2M?/20M? | ?(0.8%+1) |
| Capacitance (F) | 20nF/200nF/2?F/100?F | ?(2.5%+5) |
| Inductance (H) | 2mH/20mH/200mH/20H | ?(2%+10) |
| General Characteristics | ||
| Power | 9V battery (6F22) | |
| Display | 60mm x 54mm | |
| Product color | Red and grey | |
| Product net weight | 350g | |
| Product size | 179mm x 88mm x 39mm | |
| Standard accessories | Battery, test leads, holster, multi-purpose socket, test clips | |
| Standard individual packing | Gift box, English manual | |
| Standard quantity per carton | 20pcs | |
| Standard carton measurement | 450mm x 330mm x 340mm (0.11CBM per standard carton) | |
| Standard carton gross weight | 12kg | |
User Manual:
