SKU: 22707
UT20B Pocket Digital Multimeter | UNI-T
155,00 EGP
UT20B Pocket Digital Multimeter
- Functions:
- AC/DC current and AC voltage
- resistance
- diode test
- Square wave output
- Low battery indication
In stock
Description
UT20B Pocket Digital Multimeter | UNI-T
This UNI-T UT20B pocket digital multimeter is designed for measuring AC/DC current and DC voltage, resistance, and can be used for diodes test.
Features:
- Functions:
- AC/DC current and AC voltage
- resistance
- diode test
- Square wave output
- Low battery indication
Specifications:
| Display | 1999 digit LCD, 31 × 13 mm | |
| DC voltage | Range | 200 mV / 2000 mV / 20 V / 200 V / 300 V |
| Accuracy | ±(1.5%+2) | |
| AC voltage | Range | 200 V / 300 V |
| Accuracy | ±(2.5%+15) | |
| DC current | Range | 2000 mA / 20 mA / 200 mA |
| Accuracy | ±(2.5%+10) | |
| Resistance | Range | 200 Ω / 2000 Ω / 20 kΩ / 200 kΩ / 2000 kΩ |
| Accuracy | ±(2.5%+5) | |
| Power | 12 V battery (A23) | |
| Dimensions | 95 x 52 x 26 mm | |
| Weight | 0.12 kg | |
Package Includes:
- Multimeter UNI-T UT20B (1 pc.)
- Test lead (1 pc.)
- Battery (1 pc.)
- User manual (1 pc.)
