TMC2209 V2 Stepper Motor Driver Module

TMC2209 have all function of TMC2208, can completely replace tmc2208. At the same time, TMC2209 have better heat dissipation, support bigger current, support sensor less-homing function.

Features:

• Ultra quiet
• Large heat sink, good heat dissipation
• Support sensor less-homing function.
• Support UART mode by set jumper caps instead of welding on MKS GEN_L V2.0,skr1.3/1.4.

NOTES

• Pay attention to the connection direction, do not reverse it.
• The motor direction is opposite to that of A4988 and DRV8825, please adjust the firmware or adjust the motor wiring if you want to change A4988.
• Dir/step mode used in the printer control board, please pay attention to set the jumper cap MS1 MS2.
