SKU: 22913

SCS16UU Linear Ball Bearings Block, 16mm Inner Diameter

135,00 EGP

SCS16UU Linear Ball Bearings Block, 16mm Inner Diameter

  • Aluminum alloy linear ball bearing slide pillow block unit.
  • Chrome steel LM16UU linear bearing with light-weight aluminum housing.
  • Anodized surface, high hardness, corrosion resistance, not rust, low noise.
  • Accurate machining size for the aluminum block, convenient installation and replacement.
  • There are sealing rings on both ends of linear bearing, which has good dustproof effect and prolongs service life.

Out of stock

SKU: 22913 Category:

Description

SCS16UU Linear Ball Bearings Block, 16mm Inner Diameter

  • Aluminum alloy linear ball bearing slide pillow block unit.
  • Chrome steel LM16UU linear bearing with lightweight aluminum housing.
  • Anodized surface, high hardness, corrosion resistance, not rust, low noise.
  • Accurate machining size for the aluminum block, convenient installation, and replacement.
  • There are sealing rings on both ends of the linear bearing, which has a good dustproof effect and prolongs service life.

Specifications:

  • Bearing Model: SCS16UU
  • Inner Diameter (d): 16 mm
  • Block Width (W): 50 mm
  • Block Length (L): 44 mm
  • Block Height (F): 38.5 mm
  • Mounting Hole Pitch (B): 36 mm
  • Mounting Hole Pitch (C): 34 mm
  • Mounting Hole (S1): M5
  • Dynamic Loading (CN): 774 kg/m
  • Static Loading (CoN): 1180 kg/m

Package includes:

  • 1x SCS16UU

3D Model:
