SKU: 24771
74HC193 Binary Up/Down Counter with Clear, 16-Pin PDIP – 74193
15,00 EGP
74HC193 Binary Up/Down Counter with Clear, 16-Pin PDIP – 74193
- High-Speed CMOS Logic
- Operating Voltage: 2 to 6 V
- Compatibility: Input CMOS, Output CMOS
Out of stock
Description
74HC193 Binary Up/Down Counter with Clear, 16-Pin PDIP – 74193
A range of 74HC Family CMOS Logic Counters and Shift Registers from NXP. The 74HC Family use silicon gate CMOS technology to achieve operating speeds similar to the LSTTL family but with the low power consumption of standard CMOS integrated circuits.
- High-Speed CMOS Logic
- Operating Voltage: 2 to 6 V
- Compatibility: Input CMOS, Output CMOS
Specifications
| Attribute | Value |
| Package Type | PDIP |
| Logic Function | Counter |
| Number of Stages | 4 |
| Logic Family | HC |
| Mounting Type | Through Hole |
| Counter Type | Binary |
| Operation Mode | Down Counter, Up Counter |
| Number of Elements | 1 |
| Pin Count | 16 |
| Minimum Operating Supply Voltage | 2 V |
| Maximum Operating Supply Voltage | 6 V |
| Dimensions | 20.4 x 10.2 x 4.75mm |
| Reset Type | Asynchronous |
| Preset Type | Synchronous |
| Maximum Operating Temperature | 125 ?C |
| Direction Type | Bi-Directional |
| Minimum Operating Temperature | -40 ?C |
| Triggering Type | Positive Edge |
Package Includes:
- 1x Binary Up/Down Counter
