74HC11 Triple 3-Input AND Logic Gate, 14-Pin PDIP – 7411

74HC11 Triple 3-Input AND Logic Gate, 14-Pin PDIP – 7411

  • High-Speed CMOS Logic
  • Operating Voltage: 2 to 6 V
  • Compatibility: Input CMOS, Output CMOS
SKU: 24739
shield

Safe shopping

Your data is always protected

Sale_coupon_15

25,00EGP

In stock

In stock

12 People watching this product now!
  • shop Pick up from the Store

Everyday from 9 AM to 7 PM

  • aramex ARAMEX DELIVREY

2-3 Days

Total fees when checkout

  • product-return Return within 14 days

Payment Methods:

Description

74HC11 Triple 3-Input AND Logic Gate, 14-Pin PDIP – 7411

The 74HC Family use silicon gate CMOS technology to achieve operating speeds similar to the HCTTL family but with the low power consumption of standard CMOS integrated circuits.

  • High-Speed CMOS Logic
  • Operating Voltage: 2 to 6 V
  • Compatibility: Input CMOS, Output CMOS

Specifications

Attribute Value
Logic Function AND
Mounting Type Through Hole
Number of Elements 3
Number of Inputs per Gate 3
Schmitt Trigger Input No
Package Type PDIP
Pin Count 14
Logic Family HC
Maximum Operating Supply Voltage 5.25 V
Maximum High Level Output Current -0.4mA
Maximum Propagation Delay Time @ Maximum CL 20 ns @ 5 V
Minimum Operating Supply Voltage 4.75 V
Maximum Low Level Output Current 8mA
Maximum Operating Temperature +70 ?C
Propagation Delay Test Condition 15pF
Length 19.3mm
Height 4.57mm
Width 6.35mm
Minimum Operating Temperature 0 ?C
Dimensions 19.3 x 6.35 x 4.57mm
Package Includes:
  • 1x 74HC11 Triple 3-Input AND Logic Gate
