85,00 EGPL298N Dual H Bridge Driver Module
- Driver Model: L298N 2A
- Driver Chip: Double H Bridge L298N
- Motor Supply Voltage (Maximum): 46V
- Motor Supply Current (Maximum): 2A
- Logic Voltage: 5V
- Driver Voltage: 5-35V
- Driver Current:2A
- Logical Current:0-36mA
- Maximum Power (W): 25W
- Current Sense for each motor
- Heatsink for better performance
- Power-On LED indicator
-
120,00 EGPBIGTREETECH GC6609 V1.0 Stepper Motor Driver Module
-
350,00 EGPTMC2209 V2 Stepper Motor Driver Module
- Ultra quiet
- Large heat sink, good heat dissipation
- Support sensor less-homing function.
- Support UART mode by set jumper caps instead of welding on MKS GEN_L V2.0,skr1.3/1.4.
-
350,00 EGPBIGTREETECH Driver Adapter V0.0
-
375,00 EGPBIGTREETECH TMC2226 Stepper Motor Driver V1.0
- Operating voltage: 4.75 V to 29 V
- Maximum current consumption per coil: 2,8 A
- RMS rms: 2 A
- Step/dir operation variants: 1/8, 1/16, 1/32 or 1/64 step
- Protection against overheating in the form of attached heat sink
- Dimensions: 20.32 x 15.24 mm
-
130,00 EGPPCA9685 PWM Servo Motor Driver Module,16-Channel 12-bit
- Adjustable frequency PWM up to about 1.6KHz
- 12-bit resolution for each output – for servos, that means about 4us resolution at a 60Hz update rate
- Configurable push-pull or an open-drain output
- The output enable pin to quickly disable all the outputs
- Terminal block for power input
- Reverse polarity protection on the terminal block input
- Green power-good LED
-
1.300,00 EGPDM542 Stepper Motor Driver 4.2A, 18-50Vdc
- Input voltage 18-50VDC.
- Output current programmable, from 1A to 4.2A.
- Pulse input frequency up to 200 KHz.
- Suitable for 2-phase and 4-phase motors.
- TTL compatible and optically isolated input.
- Support PUL/DIR and CW/CCW modes.
- Operating Temperature : 70 C.
-
135,00 EGP2000W SCR Dimmer 220Vac
- Working Voltage?AC220V
- Maximum Power: 2000W
- Voltage Regulation: AC 50-220V
- Board Size?36MM * 48MM
- Thick Epoxy CCL: 1.6mm
-
250,00 EGPTMC2209 V2 Stepper Motor Driver Module
- Ultra quiet
- Large heat sink, good heat dissipation
- Support sensor less-homing function.
- Support UART mode by set jumper caps instead of welding on MKS GEN_L V2.0,skr1.3/1.4.
-
175,00 EGPTMC2208 V1.2 Stepper Motor Driver Module
- Configuration: CFG or UART
- Microsteps: Up to 1/256
- MicroPlyer: 1/256
- Logic Voltage VI0: 3-5V
- Motor Voltage :?5.5-36V
- Motor Phase Current: 1.2A RMS, 2.0A Peak
-
240,00 EGPTMC2208 V3 UART Stepper Motor Driver Module
This is TMC2208 V3.0 UART mode stepper motor driver.
UART options are UART mode (had soldered)
TMC2208 V3.0 are equipped with the wire
It?suit SKR MKS GEN L/Ramps 1.4
-
230,00 EGPTMC2208 V3 STEP/DIR Stepper Motor Driver Module
DIY options are STEP/DIR mode
TMC2208 are equipped with the wire
It?suit SKR MKS GEN Ramps 1.4
-
1.050,00 EGPSpecifications:
Input voltage: DC 9-40 v
Input current: switch power is recommended 5 A
Output current: 0.5-4.0 A
Max power consumption: 160W
Subdivision: 1, 2/A, 2/B, 4, 8, 16, 32
Work temp.: -10-4 5 ℃
Store temp.: -40-70 ℃
Size: Approx 96(L)*56(W)*35(H)mm
-
65,00 EGPL298N Motor Driver Module
- Driver Model: L298N 2A
- Driver Chip: Double H Bridge L298N
- Motor Supply Voltage (Maximum): 46V
- Motor Supply Current (Maximum): 2A
- Logic Voltage: 5V
- Driver Voltage: 5-35V
- Driver Current:2A
- Logical Current:0-36mA
- Maximum Power (W): 25W
- Current Sense for each motor
- Heatsink for better performance
- Power-On LED indicator
-
95,00 EGPDescription
Arduino is a great starting point for electronics, and with a motor shield it can also be a nice tidy platform for robotics and mechatronics. Here is a design for a full-featured motor shield that will be able to power many simple to medium-complexity projects.
Features:
2 connections for 5V servos connected to the Arduino’s high-resolution dedicated timer ? no jitter!
Up to 4 bi-directional DC motors with individual 8-bit speed selection (so, about 0.5% resolution).
Up to 2 stepper motors (unipolar or bipolar) with single coil, double coil, interleaved or micro-stepping.
4 H-Bridges: L293D chipset provides 0.6A per bridge (1.2A peak) with thermal shutdown protection, 4.5V to12V.
Pull down resistors keep motors disabled during power-up.
Big terminal block connectors to easily hook up wires (10-22AWG) and power.
Arduino reset button brought up top.
2-pin terminal block to connect external power, for separate logic/motor supplies.
Tested compatible with Mega, UNO& Duemilanove.
Dimensions(assembled): 69mm x 53mm x 14.3mm (2.7in x 2.1in x 0.6in).
-
75,00 EGPthe DRV8825 Stepper Motor Controller IC. This integrated motor driver makes interfacing with a microcontroller super easy as you only need two pins to control both the speed and the direction of the stepper motor.
-
2.250,00 EGPMDDS10 Cytron 10Amp 7V-35V Smart Drive DC Motor Driver (2 Channels) If you need a DC brushed motor driver that can accepts signal from: RC (Radio Control) PWM of microcontroller Analog voltage of Potentiometer/Variable Resistor UART/Serial command of microcontroller Well, this motor driver is perfect for you, and it supports upto 10Amps (continuous) each channel….
-
55,00 EGPA4988 Stepper Motor Driver – 2A
- Max. Operating Voltage: 35V
- Min. Operating Voltage: 8V
- Max. Current Per Phase: 2A
- Microstep resolution: Full step, ½ step, ¼ step, 1/8 and 1/16 step
- Reverse voltage protection: No
- Dimensions: 15.5 × 20.5 mm (0.6″ × 0.8″)
- Short-to-ground and shorted-load protection
- Low RDS(ON) outputs
- Thermal shutdown circuitry
-
50,00 EGPA4988 / Drv8825 – Stepper Motor Driver Expansion Board for 3D Printer
-
275,00 EGP20? AWG – 2 Core Telephone Paired Cable 1 Meter | ELSEWEDY
-
365,00 EGPTB6600 Stepper Motor Driver 4A
-
65,00 EGPFemale Stereo Audio Plug 5-Pin (3.5mm) , DIP
-
35,00 EGPZA2EE102 – Single contact block for head ?22 – 1 NC, Schneider Electric
