25GA370 Geared Motor Holder Bracket
30,00 EGP25GA370 Geared Motor Holder Bracket
- Color: Black
- Designed to fit 25GA370 Motors
- Material: Steel
- Thickness: 2mm
- Dimensions: 31x31x26mm
- Finish: Electrostatic Paint
- Weight : 13g
Showing 1–24 of 67 results
-
-
L298N Dual H Bridge Driver Module
85,00 EGPL298N Dual H Bridge Driver Module
- Driver Model: L298N 2A
- Driver Chip: Double H Bridge L298N
- Motor Supply Voltage (Maximum): 46V
- Motor Supply Current (Maximum): 2A
- Logic Voltage: 5V
- Driver Voltage: 5-35V
- Driver Current:2A
- Logical Current:0-36mA
- Maximum Power (W): 25W
- Current Sense for each motor
- Heatsink for better performance
- Power-On LED indicator
-
25GA370 DC Gear Motor With Encoder 250RP
385,00 EGP25GA370 DC Gear Motor With Encoder 250RPM 12Vdc
- Brand: Generic
- Material: Metal
- Voltage: DC 12V
- Power: 3W
- Speed: 250RPM
- Stall Torque: 3.9Kg/cm
- Dimensions:
- Output Shaft Dia.: 4mm
- Output Shaft Length: 25mm
- Motor: 50 x 24mm (without output shaft)
-
25GA370 DC Gear Motor With Encoder 200RP
385,00 EGP25GA370 DC Gear Motor With Encoder 200RPM 12Vdc
- Brand: Generic
- Material: Metal
- Voltage: DC 12V
- Power: 3W
- Speed: 200RPM
- Stall Torque: 4.5Kg/cm
- Dimensions:
- Output Shaft Dia.: 4mm
- Output Shaft Length: 25mm
- Motor: 50 x 24mm (without output shaft)
-
BIGTREETECH GC6609 V1.0 Stepper Motor Dr
120,00 EGPBIGTREETECH GC6609 V1.0 Stepper Motor Driver Module
-
TMC2209 V1.2 Stepper Motor Driver Module
350,00 EGPTMC2209 V2 Stepper Motor Driver Module
- Ultra quiet
- Large heat sink, good heat dissipation
- Support sensor less-homing function.
- Support UART mode by set jumper caps instead of welding on MKS GEN_L V2.0,skr1.3/1.4.
-
-
BIGTREETECH TMC2226 Stepper Motor Driver
375,00 EGPBIGTREETECH TMC2226 Stepper Motor Driver V1.0
- Operating voltage: 4.75 V to 29 V
- Maximum current consumption per coil: 2,8 A
- RMS rms: 2 A
- Step/dir operation variants: 1/8, 1/16, 1/32 or 1/64 step
- Protection against overheating in the form of attached heat sink
- Dimensions: 20.32 x 15.24 mm
-
PCA9685 PWM Servo Motor Driver Module,16
130,00 EGPPCA9685 PWM Servo Motor Driver Module,16-Channel 12-bit
- Adjustable frequency PWM up to about 1.6KHz
- 12-bit resolution for each output – for servos, that means about 4us resolution at a 60Hz update rate
- Configurable push-pull or an open-drain output
- The output enable pin to quickly disable all the outputs
- Terminal block for power input
- Reverse polarity protection on the terminal block input
- Green power-good LED
-
Metal Mechanical Arm Gripper Claw (2DOF)
200,00 EGPMetal Mechanical Arm Gripper Claw (2DOF)
- Degree of Freedom(DOF): 2
- Claw Material: Aluminum Alloy3
- Clamp Total Length: 108mm
- Clamp Total Width: 98mm
- Maximum Opening: 55mm
- Claw Weight: 68gm
-
DM542 Stepper Motor Driver 4.2A, 18-50Vd
1.300,00 EGPDM542 Stepper Motor Driver 4.2A, 18-50Vdc
- Input voltage 18-50VDC.
- Output current programmable, from 1A to 4.2A.
- Pulse input frequency up to 200 KHz.
- Suitable for 2-phase and 4-phase motors.
- TTL compatible and optically isolated input.
- Support PUL/DIR and CW/CCW modes.
- Operating Temperature : 70 C.
-
Mabuchi DC Motor RF-510T, 12Vdc
30,00 EGPMabuchi DC Motor RF-510T, 12Vdc
- Operating Voltage 12 volt
- RPM (Rated Maximum) 6400 rpm
- Compact, efficient, lightweight, and powerful
- Perfect for DIY Electronics, Circuitry and Science Fairs!
-
DC4233 DC Motor 220Vdc, 0.3A, 9000RPM
225,00 EGPDC4233 DC Motor 220Vdc, 0.3A, 9000RPM
- Double ball bearings at both front and rear.
- Large torque, high speed.
- Low starting current, stable and efficient.
- Metal outer case, anti-rust and durable.
- Operating voltage is DC 220V.
- Double ball bearings at both front and rear.
-
Mabuchi DC Motor RF-330T, 6Vdc
25,00 EGPMabuchi DC Motor RF-330T, 6Vdc
- Operating Voltage 6 volt
- RPM (Rated Maximum) 6400 rpm
- Compact, efficient, lightweight, and powerful
- Perfect for DIY Electronics, Circuitry and Science Fairs!
- Dimensions
- Diameter: 24.5mm
- Height: 18mm
- Shaft Diameter: 1.5mm
- Shaft Length: 11mm
-
25GA370 DC Gear Motor 12V 130RPM
270,00 EGP25GA370 DC Gear Motor 12V 130RPM
- Brand: Generic
- Material: Metal
- Voltage: DC 12V
- Power: 3W
- Speed: 130RPM
- Stall Torque: 8Kg/cm
- Dimensions:
- Output Shaft Dia.: 4mm
- Output Shaft Length: 25mm
- Motor: 50 x 24mm (without output shaft)
-
25GA370 DC Gear Motor 12V 620RPM
270,00 EGP25GA370 DC Gear Motor 12V 620RPM
- Brand: Generic
- Material: Metal
- Voltage: DC 12V
- Power: 3W
- Speed: 620RPM
- Stall Torque: 0.8Kg/cm
- Dimensions:
- Output Shaft Dia.: 4mm
- Output Shaft Length: 25mm
- Motor: 50 x 24mm (without output shaft)
-
2000W SCR Dimmer 220Vac
135,00 EGP2000W SCR Dimmer 220Vac
- Working Voltage?AC220V
- Maximum Power: 2000W
- Voltage Regulation: AC 50-220V
- Board Size?36MM * 48MM
- Thick Epoxy CCL: 1.6mm
-
25T Aluminum Servo Motor Disc Horn
17,50 EGP25T Aluminum Servo Motor Disc Horn
- Item Name: Servo Disk Horn
- Material : Aluminum
- Finish: Anodized
- Color: Silver
- Teeth no: 25T
- Hight: 5mm
- Diameter: 20mm
- Weight 4gm
-
25GA370 DC Gear Motor 12V 280RPM
270,00 EGP25GA370 DC Gear Motor 12V 280RPM
- Brand: Generic
- Material: Metal
- Voltage: DC 12V
- Power: 3W
- Speed: 280RPM
- Stall Torque: 3Kg/cm
- Dimensions:
- Output Shaft Dia.: 4mm
- Output Shaft Length: 25mm
- Motor: 50 x 24mm (without output shaft)
-
MKS OSC V1 Stepper Motor Speed Controlle
264,50 EGPMKS OSC V1 Stepper Motor Speed Controller Module
- Signal type: PWM/ Pulse
- Frequency range: high 5.4k-160khz, medium 540-16.6khz and low 80-2.4khz
- Direction: clockwise / counterclockwise
- Voltage: 8v-24v
- Color: black
- Material: PC + metal
- Dimensions: 58×38.6mm
-
TMC2209 V2 Stepper Motor Driver Module
250,00 EGPTMC2209 V2 Stepper Motor Driver Module
- Ultra quiet
- Large heat sink, good heat dissipation
- Support sensor less-homing function.
- Support UART mode by set jumper caps instead of welding on MKS GEN_L V2.0,skr1.3/1.4.
-
TMC2208 V1.2 Stepper Motor Driver Module
175,00 EGPTMC2208 V1.2 Stepper Motor Driver Module
- Configuration: CFG or UART
- Microsteps: Up to 1/256
- MicroPlyer: 1/256
- Logic Voltage VI0: 3-5V
- Motor Voltage :?5.5-36V
- Motor Phase Current: 1.2A RMS, 2.0A Peak
-
TMC2208 V3 UART Stepper Motor Driver Mod
240,00 EGPTMC2208 V3 UART Stepper Motor Driver Module
This is TMC2208 V3.0 UART mode stepper motor driver.
UART options are UART mode (had soldered)
TMC2208 V3.0 are equipped with the wire
It?suit SKR MKS GEN L/Ramps 1.4 -
23HS5628 Nema23 Stepper Motor
750,00 EGP23HS5628 Nema23 Stepper Motor
- Model: 23HS5628
- Shaft Diameter: 8mm
- Step Angle: 1.8?
- Motor Length: 56mm
- Rated Current: 2.5A
- Phase Resistance: 0.9 ohms
- Phase Inductance: 2.5mH
- Holding Torque: 12.6Kg.cm
- Lead Wire: No.4
- Motor Wire: The default length is 30cm
